INA KWVE35-B-E-V2-G3 Rulman
Fiyatı: 3,023.97 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE35-B-E-V2-G3 INA |
| Üretici No | 0605850640340 |
| Alternatif Kodu |
KWVE35-B-E-G3-V2 |
| EAN | 4054366781642 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 41,3 |
| Dış (D) MM | 100 |
| En (B) MM | 112 |
| İç (d) Inch | 1.626 |
| Dış (D) Inch | 3.937 |
| En (B) Inch | 4.4094 |
| Ağırlık | 1.893 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 100 |
| Overall length carriage (L) mm | 112 |
| Dynamic load rating (C) | 38000 |
| Static load rating (C 0) | 72000 |
| Static moment rating about X axis (M 0x) | 1465 |
| Static moment rating about Y axis (M 0y) | 1020 |
| Static moment rating about Z axis (M 0z) | 1020 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-B-E, standard carriage, four-row, full complement, expanded type |
| B | Standard Carriage, Four-Row, Full Complement Ball Set |
| E | Expanded Design (Carriage Without Screw Threads) |
| V2 | Preload Class 2 |
| G3 | Precision Class 3 |
