INA KWVE35-B-E-V2-G3 Rulman Resim 5
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 3,023.97 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
41,3 |
| Dış (D) MM |
100 |
| En (B) MM |
112 |
| İç (d) Inch |
1.626 |
| Dış (D) Inch |
3.937 |
| En (B) Inch |
4.4094 |
| Ağırlık |
1.893 kg
|
Ürün Özellikleri
Data from Schaeffler (medias)
| Width carriage (B) mm |
100 |
| Overall length carriage (L) mm |
112 |
| Dynamic load rating (C) |
38000 |
| Static load rating (C 0) |
72000 |
| Static moment rating about X axis (M 0x) |
1465 |
| Static moment rating about Y axis (M 0y) |
1020 |
| Static moment rating about Z axis (M 0z) |
1020 |
| ECLASS number |
23-30-04-90 |
| ECLASS2 number |
23-30-04-90 |
| Medias description |
Carriages KWVE..-B-E, standard carriage, four-row, full complement, expanded type |
Suffix description
| B |
Standard Carriage, Four-Row, Full Complement Ball Set |
| E |
Expanded Design (Carriage Without Screw Threads) |
| V2 |
Preload Class 2 |
| G3 |
Precision Class 3 |
