INA LCJT40-XL-N-SML Rulman
Fiyatı: 1,572.19 ₺
Özellikler
| Marka | INA |
| Ürün No | LCJT40-XL-N-SML INA |
| Üretici No | 0008578070319 |
| Alternatif Kodu |
LCJT40-N-SML |
| EAN | 4012802798111 |
| Kategori | Gövde ve Yatak - Montaj |
| İç (d) MM | 40 |
| Dış (D) MM | 172 |
| En (B) MM | 59,1 |
| İç (d) Inch | 1.5748 |
| Dış (D) Inch | 6.7717 |
| En (B) Inch | 2.3268 |
| Ağırlık | 1.66 kg |
| Fok | 2F - Y-Rulmanlar için Standart Conta |
| Yağlama | Standart Yağlama |
| Özel Muamele | No Special Treatment |
| Flange width (L) mm | 105 |
| Height flange (H) mm | 172 |
| Total height unit (U) mm | 59,1 |
| Radial Static Load Rating C0r (N) | 19800 |
| Radial Dynamic Load Rating Cr (N) | 34500 |
| Temel statik yük derecesi, radyal (C 0r) | "19800.0000" |
| ECLASS number | 23-05-16-02 |
| ECLASS2 number | 23-05-16-02 |
| Medias description | Housing units LCJT, two-bolt flanged housing units, cast iron, eccentric locking collar, L seals, for temperatures from -40°C to +180°C |
| XL | X-Life |
| N | Cast Iron Housing With Undercut Slot For End Caps |
| SML | More Clearance Between Bearings And Housing, This Has No Influence On The Item Without The Suffix SML |
