INA LCJT40-XL-N-SML Rulman Resim 3
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 1,572.19 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
40 |
| Dış (D) MM |
172 |
| En (B) MM |
59,1 |
| İç (d) Inch |
1.5748 |
| Dış (D) Inch |
6.7717 |
| En (B) Inch |
2.3268 |
| Ağırlık |
1.66 kg
|
Ürün Özellikleri
| Fok |
2F - Y-Rulmanlar için Standart Conta |
| Yağlama |
Standart Yağlama |
| Özel Muamele |
No Special Treatment |
Data from Schaeffler (medias)
| Flange width (L) mm |
105 |
| Height flange (H) mm |
172 |
| Total height unit (U) mm |
59,1 |
| Radial Static Load Rating C0r (N) |
19800 |
| Radial Dynamic Load Rating Cr (N) |
34500 |
| Temel statik yük derecesi, radyal (C 0r) |
"19800.0000" |
| ECLASS number |
23-05-16-02 |
| ECLASS2 number |
23-05-16-02 |
| Medias description |
Housing units LCJT, two-bolt flanged housing units, cast iron, eccentric locking collar, L seals, for temperatures from -40°C to +180°C |
Suffix description
| XL |
X-Life |
| N |
Cast Iron Housing With Undercut Slot For End Caps |
| SML |
More Clearance Between Bearings And Housing, This Has No Influence On The Item Without The Suffix SML |
