INA RWU25-E-H-V3-G2 Rulman
Fiyatı: 4,367.62 ₺
Özellikler
| Marka | INA |
| Ürün No | RWU25-E-H-V3-G2 INA |
| Üretici No | 0649925001430 |
| Alternatif Kodu |
RWU25-E-H-G2-V3 |
| EAN | 4054364489496 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 23 |
| Dış (D) MM | 48 |
| En (B) MM | 91 |
| İç (d) Inch | 0.9055 |
| Dış (D) Inch | 1.8898 |
| En (B) Inch | 3.5827 |
| Ağırlık | 0.65 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 48 |
| Overall length carriage (L) mm | 91 |
| Dynamic load rating (C) | 28000 |
| Dynamic load rating (C 0) | 65000 |
| Static moment rating about X axis (M 0x) | 350 |
| Static moment rating about Y axis (M 0y) | 760 |
| Static moment rating about Z axis (M 0z) | 680 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | High, narrow carriage with full complement recirculating roller system for linear recirculating roller bearing and guideway assembly, for oil or grease lubrication |
| E | Version |
| H | High Carriage |
| V3 | Preload Class 3 |
| G2 | Precision Class 2 |
