INA RWU25-E-H-V3-G2 Rulman Resim 5
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 4,367.62 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
23 |
| Dış (D) MM |
48 |
| En (B) MM |
91 |
| İç (d) Inch |
0.9055 |
| Dış (D) Inch |
1.8898 |
| En (B) Inch |
3.5827 |
| Ağırlık |
0.65 kg
|
Ürün Özellikleri
Data from Schaeffler (medias)
| Width carriage (B) mm |
48 |
| Overall length carriage (L) mm |
91 |
| Dynamic load rating (C) |
28000 |
| Dynamic load rating (C 0) |
65000 |
| Static moment rating about X axis (M 0x) |
350 |
| Static moment rating about Y axis (M 0y) |
760 |
| Static moment rating about Z axis (M 0z) |
680 |
| ECLASS number |
23-30-04-90 |
| ECLASS2 number |
23-30-04-90 |
| Medias description |
High, narrow carriage with full complement recirculating roller system for linear recirculating roller bearing and guideway assembly, for oil or grease lubrication |
Suffix description
| E |
Version |
| H |
High Carriage |
| V3 |
Preload Class 3 |
| G2 |
Precision Class 2 |
